SunPower P17 335W Specs:
Description:
Brand new SunPower P17 335W are polycrystalline solar panels. These are brand new panels, never installed. They were probably manufactured in 2016. Each panel includes the two cables with MC4 connectors. We guarantee the panels to work on installation.
These P-Series panels deliver more energy due to higher performance in row-to-row shading, allowing closer row spacing and more energy from the same area. The parallel circuitry limits shading loss to the shaded area only instead of much larger sections of energy loss in standard panels.
Warranty:
These do not have the manufactures warranty, but we offer a 1 year warranty with the option of extending the warranty for an additional 4 years, for a total warranty of 5 years.
Features:
Specifications:
SanTan Solar T Series Spec Sheet
280W
Electrical Data Standard Test Conditions
Peak Power Watts-PMAX (Wp) – 280
Power output Tolerance-PMAX – 0/+3
Maximum Power Voltage-VMP (V) – 36.0
Maximum Power Current-iMPP (A) – 7.78
Open Circuit Voltage-VoC (V) – 44.4
Short Circuit Current-iSC (A) – 8.33
Module Efficiency ηm (%) – 14.4
Electrical Data Nominal Operating Cell Temperature
Maximum Power-PMAX (Wp) – 204
Maximum Power Voltage-VMP (V) – 32.8
Maximum Power Current-iMPP (A) – 6.22
Open Circuit Voltage (V)-VoC (V) – 40.7
Short Circuit Current (A)-iSC (A) – 6.75
Mechanical Data
Solar cells Multicrystalline 156 × 156mm (6 inches)
Cell orientation 72 cells (6 × 12)
Module dimensions 1956 × 992 × 46mm (77 × 39.05 × 1.81 inches)
Weight 28kg (61.7 lb)
Glass high transparency solar glass 4mm (0.16 inches)
Frame Anodized aluminium alloy
J-Box iP 65 rated
Cables Photovoltaic Technology cable 4.0mm² (0.006 inches²), 1250mm (49.2 inches)
Connector original MC4
Temperature Ratings
nominal operating Cell Temperature (noCT) 46°C (±2°C)
Temperature Coefficient of PMAX – 0.44%/°C
Temperature Coefficient of VoC – 0.33%/°C
Temperature Coefficient of ISC 0.046%/°C
Maximum System Voltage 1000V DC/ 600V DC
245W
Electrical Data Standard Test Conditions
Peak Power Watts-PMAX (Wp) – 245
Power output Tolerance-PMAX – 0/+3
Maximum Power Voltage-VMP (V) – 30.2
Maximum Power Current-iMPP (A) – 8.13
Open Circuit Voltage-VoC (V) – 37.5
Short Circuit Current-iSC (A) – 8.68
Module Efficiency ηm (%) – 15.0
Electrical Data Nominal Operating Cell Temperature
Maximum Power-PMAX (Wp) – 178
Maximum Power Voltage-VMP (V) – 26.8
Maximum Power Current-iMPP (A) – 6.64
Open Circuit Voltage (V)-VoC (V) – 34.2
Short Circuit Current (A)-iSC (A) – 7.10
Mechanical Data
Solar cells Multicrystalline 156 × 156mm (6 inches)
Cell orientation 60 cells (6 × 10)
Module dimensions 1650 × 992 × 35mm (64.95 × 39.05 × 1.37 inches)
Weight 18.6kg (41.0 lb)
Glass high transparency solar glass 3.2mm (0.13 inches)
Frame Anodized aluminium alloy
J-Box iP 65 rated
Cables Photovoltaic Technology cable 4.0mm² (0.006 inches²),1000mm (39.4 inches)
Connector original MC4
Temperature Ratings
nominal operating Cell Temperature (noCT) 45°C (±2°C)
Temperature Coefficient of PMAX – 0.43%/°C
Temperature Coefficient of VoC – 0.32%/°C
Temperature Coefficient of ISC 0.047%/°C
Maximum System Voltage 1000V DC/ 600V DC
SanTan Serie T Ficha Técnica
280W
Electrical Data Standard Test Conditions
Potencia Watts-PMAX (Wp) – 280
Potencia output Tolerance -PMAX – 0/+3
Voltaje -VMP (V) – 36.0
Corriente -iMPP (A) – 7.78
Voltaje de Circuito Abierto -VoC (V) – 44.4
Corriente de Cortocircuito -iSC (A) – 8.33
Eficiencia ηm (%) – 14.4
Electrical Data Nominal Operating Cell Temperature
Maximum Power-PMAX (Wp) – 204
Maximum Power Voltage-VMP (V) – 32.8
Maximum Power Current-iMPP (A) – 6.22
Open Circuit Voltage (V)-VoC (V) – 40.7
Short Circuit Current (A)-iSC (A) – 6.75
Mechanical Data
Solar cells Multicrystalline 156 × 156mm (6 inches)
Cell orientation 72 cells (6 × 12)
Module dimensions 1956 × 992 × 46mm (77 × 39.05 × 1.81 inches)
Weight 28kg (61.7 lb)
Glass high transparency solar glass 4mm (0.16 inches)
Frame Anodized aluminium alloy
J-Box iP 65 rated
Cables Photovoltaic Technology cable 4.0mm² (0.006 inches²), 1250mm (49.2 inches)
Connector original MC4
Temperature Ratings
nominal operating Cell Temperature (noCT) 46°C (±2°C)
Temperature Coefficient of PMAX – 0.44%/°C
Temperature Coefficient of VoC – 0.33%/°C
Temperature Coefficient of ISC 0.046%/°C
Maximum System Voltage 1000V DC/ 600V DC
245 W
Data Eléctrica Condiciones Estándares
Potencia Watts-PMAX (Wp) – 245
Potencia output Tolerance-PMAX – 0/+3
Voltaje -VMP (V) – 30.2
Corriente -iMPP (A) – 8.13
Voltaje de Circuito Abierto-VoC (V) – 37.5
Corriente de Cortocircuito -iSC (A) – 8.68
Eficiencia ηm (%) – 15.0
Data Eléctrica Nominal Operación Cell Temperatura
Maximum Power-PMAX (Wp) – 178
Maximum Power Voltage-VMP (V) – 26.8
Maximum Power Current-iMPP (A) – 6.64
Open Circuit Voltage (V)-VoC (V) – 34.2
Short Circuit Current (A)-iSC (A) – 7.10
Data Mecánica
Solar cells Multicrystalline 156 × 156mm (6 inches)
Cell orientation 60 cells (6 × 10)
Module dimensions 1650 × 992 × 35mm (64.95 × 39.05 × 1.37 inches)
Weight 18.6kg (41.0 lb)
Glass high transparency solar glass 3.2mm (0.13 inches)
Frame Anodized aluminium alloy
J-Box iP 65 rated
Cables Photovoltaic Technology cable 4.0mm² (0.006 inches²),1000mm (39.4 inches)
Connector original MC4
Coeficientes de Temperatura
nominal operating Cell Temperature (noCT) 45°C (±2°C)
Temperature Coefficient of PMAX – 0.43%/°C
Temperature Coefficient of VoC – 0.32%/°C
Temperature Coefficient of ISC 0.047%/°C
Maximum System Voltage 1000V DC/ 600V DC
SanTan Serie X Ficha Técnica
Especificaciones Mecánicas
Formato 79.3 in × 39.4 in × 1.38 in (con marco) (2015 mm × 1000 mm × 35 mm)
Peso 51.8 lbs (23.5 kg)
Portada 0.13 in (3.2 mm) Vidrio termostatizado con tecnología anti-reflexiva
Contraportada Filme compuesta
Marco Aluminio anodizado
Célula 6 × 24 monocristalino solar media-célula
Caja de Conexiones 2.76-3.35 in × 1.97-2.76 in × 0.51-0.83 in (70-85 mm × 50-70 mm × 13-21 mm), Clase de protección IP67, con diodos de circunvalación
Cable 4 mm² Solar cable; (+) ≥ 53.1 in (1350 mm), (−) ≥ 53.1 in (1350 mm)
Conector Multi-Contacto MC4-EVO2, JMTHY PV-JM601A, IP68 or Renhe 05-6, IP67
Características eléctricas
CLASE DE POTENCIA 380
RENDIMIENTO MÍNIMO A CONDICIONES ESTANDAR, STC1 (TOLERANCIA DE POTENCIA +5 W / − 0 W)
Potencia MPP1 PMPP [W] 380
Corriente de Cortocircuito1 ISC [A] 10.05
Voltaje de Circuito Abierto1 VOC [V] 47.95
Corriente a MPP IMPP [A] 9.57
Voltaje a MPP VMPP [V] 39.71
Eficiencia1 η [%] ≥ 18.9
RENDIMIENTO MÍNIMO A CONDICIONES ESTANDAR DE OPERACIÓN, NMOT2
Potencia a MPP PMPP [W] 283.9
Corriente de Cortocircuito ISC [A] 8.10
Voltaje de Circuito Abierto VOC [V] 45.12
Corriente a MPP IMPP [A] 7.53
Voltaje a MPP VMPP [V] 37.69
Coeficientes de Temperatura
Coeficientes de Temperatura de ISC α [% / K] + 0.04
Coeficientes de Temperatura de VOC β [% / K] − 0.28
Coeficientes de Temperatura de PMPP γ [% / K] − 0.37
Temperatura de Operación Normal NMOT [°F] 109 ± 5.4 (43 ± 3 °C)
Propiedades de Diseño de Sistema
Voltaje Máximo del Sistema VSYS [V] 1500 (IEC) / 1500 (UL)
Clase de Seguridad II
Capacidad Máxima del Fusible de la Serie [A DC] 20
Clasificación de Fuego C (IEC) / TYPE 1 (UL)
Carga Máxima de Diseño, Empujar / Jalar (UL)2 [lbs/ft2] 75 (3600 Pa) / 33 (1600 Pa)
Temperatura Permitido del Modelo al Funcionar − 40 °F up to +185 °F (− 40 °C up to +85 °C)
Carga Máxima de Prueba, Empujar / Jalar (UL)2 [lbs/ft2] 113 (5400 Pa) / 50 (2400 Pa) 2
Información de Empacar
Numero de Modulo por Paleta 29
Numero de Paletas por 53′ Trailer 26
Numero de Paletas por 40′ High Cube Container 22
Dimensiones de Paleta ( L × W × H ) 81.9 in × 45.3 in × 46.7 in (2080 mm × 1150 mm × 1185 mm)
Peso de Paleta 1635 lbs (742 kg)
SunPower 327W Specs:
Description:
These used SunPower 327W high efficiency 96 cell mono solar panels are in good condition. There is normal wear and tear for used panels. The panels are outputting about 60V and 5.8 amps with a voltmeter. They were probably manufactured between 2013 and 2017.
Warranty:
These are sold without SunPower warranty. We warranty them for 1 year, with the option to buy an extended warranty of 4 years, for a warranty total of 5 years.
Features:
Specifications:
