Midnite Solar Circuit Breaker 15A
MidNite’s 15A 150VDC DIN Rail Mount breakers are rated to break the full rated load at the rated voltage repeatedly.
Midnite Solar Circuit Breaker 15A 150VDC DIN Rail Mount
MidNite Solar breakers are rated to break the full rated load at the rated voltage repeatedly. MNEPV breakers are the same as CBI QY breakers except the standard used is inadequate for the solar industry. MidNite breakers have been evaluated by ETL to 150VDC and are listed for US and Canada. All of the NRTL listings still apply. Breakers ordered under the CBI part numbering system will not be listed for 150VDC and in many cases are not suitable for the solar industry.
- Breaker Torque Value: 20 In-Lbs (2.3NM)
- Environmental Rating - Type 1 (Indoor)
- DC Voltage Rating - 150VDC
- Wire Size Range - 14 to 6 AWG
- Width - .51 in (13mm)
- Number of poles - 1
- 10,000 AIC
