SUNON12 | RUiXU Single/Split-Phase Off-Grid Inverter | 12kW | UL1741

Original price was: $2,099.00.Current price is: $1,999.00.

-

The Ruixu SUNON12 is a 12 kW all-in-one off-grid inverter for 48V batteries, combining a 24 kW dual-MPPT solar charger, a 250A battery charger and split-phase output in one wall-mounted unit.

  • 12,000W continuous, 18,000VA peak, 120/240V split-phase
  • 24 kW PV input on 2 MPPTs (12 kW each, 500V max)
  • Up to 250A charging from solar, grid or generator combined
  • Generator input, 125A bypass and 60A smart load output
  • Parallel up to 6 units (72 kW) · UL1741 · 5-year warranty

Batteries, solar panels and Wi-Fi module sold separately. Indoor installation (IP20).

SKU: RUIXU-12 Categories: , , Brand:

Off-Grid Inverter · 48V · Split-Phase

Ruixu SUNON12 12kW All-In-One Off-Grid Inverter

One unit that does the work of an inverter, a solar charge controller and a battery charger. The SUNON12 delivers 12 kW of continuous 120/240V power, accepts up to 24 kW of solar on two independent MPPTs, and charges your 48V battery bank at up to 250A from solar, the grid and a generator together.

12 kW
Continuous output · 18 kVA peak
24 kW
PV input on 2 MPPTs
250A
Max battery charging
72 kW
Up to 6 units in parallel

Built for Off-Grid Homes, Cabins and Shops

The SUNON12 is designed for properties that run on solar and batteries: full-time off-grid homes, cabins, farms, barns and workshops. Its 6 HP motor load capacity and 18,000VA peak output help start well pumps, air conditioners and shop tools, while the selectable 120V/240V generator input and grid input keep the batteries charged through long cloudy stretches. It runs off-grid and does not export power to the utility.

Key Features

Hybrid charging (SUB mode)

Charge from solar and the grid at the same time, up to 250A combined, so batteries recover quickly after a heavy night or a low-sun day.

Two 12 kW MPPT inputs

24 kW of PV input across two trackers (90–450V MPPT range, 500V max open-circuit voltage, 32A per input) with 99.9% tracking efficiency.

Generator-ready

Dedicated generator input with selectable 120V or 240V operation charges the batteries and carries loads when solar can’t.

125A bypass output

When grid or generator power is available, loads pass through up to 125A with seamless switching (about 10 ms).

60A smart load output

A second output that switches on and off automatically by battery voltage, state of charge or PV input: ideal for non-essential loads like water heaters or pumps.

Time-sharing and parallel

Schedule charging and discharging to fit your rates or routine, and parallel up to 6 units for 72 kW systems.

Built-in breakers

Integrated breakers for the inverter input, generator, load, smart load and battery reduce external hardware.

Monitoring and control

Touchscreen display, RS485 / CAN / USB / dry-contact communication, and an optional Wi-Fi module for app monitoring.

Rapid shutdown support

Supports rapid shutdown to de-energize the PV array for first responders (compatible module-level devices required).

Specifications

Rated output power12,000W
Max output power18,000VA
Output voltage120/240Vac, single-phase or split-phase, 50/60Hz, pure sine wave
Motor load capacity6 HP
Load outputsLoad 125A + smart load 60A
Transfer time10 ms (typical)
Battery48V nominal (40–60Vdc); lithium-ion, lead-acid or user-defined
Max charging currentSolar 250A · grid/generator 160A · hybrid 250A
PV input2 MPPTs · 12,000W + 12,000W · 32A / 32A · 500Vdc max Voc · 90–450Vdc MPPT range
Grid and generator input120Vac (L1/N, L2/N) / 240Vac (L1/L2), 85–140Vac per phase, 50/60Hz; generator input 120V or 240V selectable
EfficiencyMPPT tracking 99.9% · inverter up to 93%
Parallel1–6 units (up to 72 kW)
CommunicationRS485, CAN, USB, dry contact; Wi-Fi module optional
Protection ratingIP20, indoor only
Operating temperature-10 to 55°C (derates above 45°C)
Dimensions30.91 Ă— 19.09 Ă— 6.33 in (785 Ă— 485 Ă— 160.8 mm)
Weight84.88 lb (38.5 kg)
CertificationsUL1741, FCC Part 15 Class B
Warranty5 years

Specifications from the Ruixu SUNON12 datasheet.

Installation note
Batteries, solar panels, the Wi-Fi module, wiring, disconnects and mounting hardware are sold separately. Install indoors in a ventilated space. Design and installation must follow Ruixu’s manual and applicable electrical code, and may require a licensed electrician and permits.
Weight 100 lbs
Dimensions 34 × 24 × 10 in
Output (V)

120V/240V

Application

Off-Grid

Battery Voltage (V)

48V

Brand

Inverter Size (KW)

10KW-15KW

Inverter Type

All-in-one Inverter

ruixu-sunon12-manualDownload
Manual
ruixu-sunon12-datasheetDownload
Datasheet
ruixu-sunon12-certDownload
UL1741 Certification
